2. ARI731
電子型錄下載
ARI731.pdf| Rated load |
20、30、50、100、200、300、500、1000、2000 kg |
|---|---|
| Comprehensive error | ≤±0.2% |
| Non-linearity | 0.2% |
| Rated output | 1.5 ±20%mV/V |
| Creep | ±0.1%F.S. / 30min. |
| Zero balance | ±1.0% F.S. |
| Input resistance | 800~1000 Ω |
| output resistance | 800~1000 10Ω |
| Insulation resistance | ≥5000MΩ / 100VDC |
| Temp.effect on span | ±0.05%F.S. / 10℃ |
| Temp.effect on zero | ±0.05%F.S. / 10℃ |
| Compensated temp range | -10～60℃ |
| Use temp range | -20～80℃ |
| Excitasion voltage | 5～12V |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Defend grade | IP67 |
